EnerPro 65V/12A-Tr/FM
Article Nr. : 296002
Two-pole surge arrester for operating currents up to 12 A and a nominal impulse discharge current of 20 kA (8/20 µs) for sensitive electronical devices.
- With remote signalling contact (FM)
- Arresters for Cathodic Corrosion Protection Systems
- Two-stage design
- High performance surge protector
- Mounting on 35 mm DIN rail (EN 60715)
- Operating current: 12 A
- Maximum acceptable DC continuous operating voltage of 65 V DC
- With filter
- EAC certification
| Max. continuous operating voltage DCUc | 65 V= |
| Rated load currentIL | 12 A |
| Protection level at 1kV/μsUp | ≤ 350 V |
| Nominal discharge current (8/20 µs)In | 20 kA |
| Max. impulse discharge current (8/20 µs)Imax | 40 kA |
| Lightning impulse current (10/350 µs)Iimp | 5 (2,5 As) kA |
| Nominal alternating discharge current (50 Hz) | 20 (5x1s, 50Hz, 3min. Pause) A/s |
| Response timetA | ≤ 25 ns |
| Operating temperature rangeTU | -40 - +80 °C |
| Max. conductor cross section | stranded 35/fine stranded 25 mm² |
Additional Information
| Max. connection torque for terminals | 4,0 Nm |
| Enclosure material / colour | polycarbonate (halogen-free) UL 94-V0 / yellow |
| Degree of protection (IEC EN 60529) | IP 20 |
| Mounting | 35 mm DIN rail (EN 60715) |
| FM contact / contact type | break contact |
| Switching capacity FM | 250 V/2 A |
| Max. conductor cross section FM | 1,5 mm² |
